SPECIFICATIONS :  GK-37
CONFIGURE :
Colors available :  Red,yellow,blue,black
Features :  *
Decals (Y/N) :  Y
Tool kit (Y/N) :  Y
Remote start (Y/N) :  N
Remote engine stop (Y/N) :  N
Remote alarm (Y/N) :  N
Speed limiter (Y/N) :  Y
Assembly required :  Tire,seat,steering wheel

ENGINE INFO :
Engine type :  Chain
Engine brand :  *
Displacement :  110cc
Cooling :  Air-cooled
Max horsepowe :  2.9 h.p./7000~8000r/min
Max torque :  5.6n.m/5600~6000r/min
Bore*stroke :  1.85*1.95inches
Max speed :  24.9mile/h
Climbing ability :  7degree
Ignition :  C.D.I
Starting system :  Electric
Battery :  12V/4Ah
Carburetor brand :  PZ19
Engine oil :  SAE15W/40SF

Gear oil :  *
CHASSIS ETC :
Clutch :  semi auto
Transmission :  *
Driveline :  Chain-drive
Driving wheel :  Rear wheel drive
Suspension,front/rear :  Double a-arm/single a-arm
Brakes,front/rear :  Rear disc
Brake operation :  Foot
Tires,front/rear :  145/70-6 / 145/70-6
Fuel capacity/type :  1.3gal
Weight,G.W./N.W :  330.7/ 297.6lbs
Max load :  88lbs
DIMENSIONS :
Wheelbase :  49.6inches
OA L*W*H :  63.8*29.1*43.3inches
Height to seat :  10.6inches
Min ground clearance :  3.3inches
Carton size :  62.2*29.5*20.7inches

Shipping info :  110pcs/40HQ
